Description
Product Attributes
| TYPE | DESCRIPTION | SELECT ALL |
| Categories | Connectors, Interconnects | |
|---|---|---|
| Circular Connectors | ||
| Manufacturer | Hirose Electric Co Ltd | |
| Series | HR30 | |
| Packaging | Tray | |
| Part Status | Active | |
| Connector Type | Receptacle, Male Pins | |
| Number of Positions | 3 (Power) | |
| Shell Size – Insert | 6 | |
| Shell Size, MIL | – | |
| Mounting Type | Panel Mount | |
| Mounting Feature | Bulkhead – Rear Side Nut | |
| Termination | Solder Cup | |
| Fastening Type | Push-Pull | |
| Orientation | Keyed | |
| Shell Material | Polyphenylene Sulfide (PPS) | |
| Shell Finish | – | |
| Contact Finish – Mating | Gold | |
| Color | Black | |
| Ingress Protection | IP67/IP68 – Dust Tight, Waterproof | |
| Material Flammability Rating | UL94 V-0 | |
| Features | – | |
| Shielding | – | |
| Current Rating (Amps) | 5A | |
| Voltage Rating | 100VAC, 140VDC | |
| Cable Opening | – | |
| Operating Temperature | -25°C ~ 85°C | |
| Backshell Material, Plating | – | |
| Contact Material | Brass | |
| Contact Finish Thickness – Mating | 8.00µin (0.203µm) | |
| Insert Material | Polyphenylene Sulfide (PPS) | |
| Applications | Industrial, Marine, Medical |
